Electrical Test Equipment

  • DC-100 kHz, 1,000 Watt CW, multiple amplifiers
  • Power Op-Amps, ±36 V, ±12 Amp, DC-100 kHz, multiple amplifiers
  • 10 kHz-200 MHz, multiple amplifiers up to 2,500 Watt CW
  • 200-1,000 MHz, multiple amplifiers up to 1,000 Watt CW
  • 1-18 GHz, multiple amplifiers up to 500 Watt CW
  • 18-40 GHz, 10 Watt CW
  • 200-1,300 MHz, 5,000 Watt pulsed source

  • Capable of generating in excess of 200 V/m from 10 kHz-40 GHz electric field and DC-30 MHz magnetic field
  • Emissions testing – several antennas to allow for multiple test setups
  • Susceptibility testing – several antennas to allow for multiple test setups
  • Multiple Helmholtz coils
  • Multiple single loop magnetic field coils for DC magnetic field testing of very large items, up to 17 ft. (L) x 10 ft. (H) – capable of generating a DC magnetic field of 20 Gauss
  • Multiple magnetic field coils for RS101 testing

  • Multiple current monitoring probes for 5 Hz-1 GHz
  • Multiple active current monitoring probes for DC-100 MHz
  • Multiple current injection probes for 10 kHz-1 GHz

  • 50 µH LISNs for MIL-STD-461D, E, and F, including other specifications (several available)
  • 50 µH LISNs for FCC/CE testing, including other specifications (several available)
  • 5 µH LISNs for automotive, RTCA/DO-160, and MIL-STD-461A, Notice 4, including other specifications (several available)
  • 57 µH LISNs for MIL-STD-461A, Notice 4 (several available)
  • 50 µF capacitors for MIL-STD-461G and 5 µF capacitors for RTCA/DO-160, including other specifications (several available)
  • UK DEF Standards LISNs (several available)
  • TEMPEST LISNs (several available)
  • Other specialized LISNs, filters, and networks available for specialized testing up to 300 Amp

Testing to MIL-STD-461A, B, C, D, E, F, and G

DTB offers some of the most unique test facilities in the world. Our EMI/EMC test facilities have been designed to handle a wide variety of EMI/EMC testing.

DTB’s test equipment provides the right environment in which to conduct your test program in an efficient manner – all under one roof. Our equipment includes multiple receivers and signal sources, transient test systems and generators, power amplifiers, antennas, probes, and line impedance stabilization networks (LISNs).

Along with our unique test facilities, DTB also offers a full assortment of equipment to support your test program.

  • Multiple EMI receivers for the range of 20 Hz-40 GHz
  • Multiple signal sources for the range of DC-40 GHz
  • Transient test systems for:
    • MIL-STD-461A, B, and C, Methods CS06 and RS02 (two available)
    • MIL-STD-461F, Method CS106 (two available)
    • MIL-STD-461D, E, and F, Method CS115 (two available)
    • MIL-STD-461D, E, and F, Method CS116 (two available)
  • 50 µsec pulse generator for CS06/RS02-type testing
  • MIL-STD-1399 transient generator
  • RTCA/DO-160, Section 17 transient generator (three available)
  • ABD0100.1.8.1, AMD24C voltage spike testing (fully compliant for A350, M400, A380, and RTCA/DO-160, Section 17)
  • Several custom transient generators for automotive testing
